Carrier Aggregation Technology

- Overview

Carrier Aggregation (CA) is a technology that combines two or more frequency carriers into a single data channel to increase network capacity and data transfer rates.

This is achieved by allowing a user's device to use multiple carriers simultaneously, which boosts both peak and average data speeds.

CA is a key feature in mobile systems like 4G LTE-Advanced and 5G, enabling mobile network operators to enhance user throughput and better utilize fragmented spectrum resources.

- How Carrier Aggregation Works

• Combining carriers: A device can simultaneously connect to multiple carriers—either in the same frequency band (intra-band) or from different bands (inter-band).
• Increased bandwidth: By adding these carriers, a wider virtual channel is created, leading to significantly higher data rates.
• Primary and secondary carriers: The system uses a primary component carrier (PCC) and one or more secondary component carriers (SCC) to manage data flow efficiently.

- Types of Carrier Aggregation

• Intra-band, contiguous: Combining adjacent channels within the same frequency band (the easiest type).
• Intra-band, non-contiguous: Combining channels within the same band that are not next to each other.
• Inter-band: Combining carriers from different frequency bands (more complex).

- Benefits

• Higher data rates: CA can significantly increase download and upload speeds, improving performance for activities like streaming video and online gaming.
• Better spectrum use: It helps network operators make more efficient use of the available spectrum, especially when it is fragmented across different bands.
• Improved capacity: By using more spectrum, the network can handle more simultaneous users and improve overall efficiency.
• Enhanced coverage and reliability: Aggregating carriers can help extend coverage and provide a more stable connection.

- Applications

• Mobile networks: CA is essential for 4G and 5G, enabling higher speeds and capacity.
• 5G and beyond: In 5G New Radio (NR), CA provides multi-connectivity and allows for asymmetric upload/download speeds, using up to 700 MHz of bandwidth in millimeter wave frequencies or up to 400 MHz in the sub-7 GHz band.
• Wi-Fi: The similar concept of combining contiguous channels in Wi-Fi is called channel bonding.

- Evolution of Carrier Aggregation (CA) from LTE-Advanced to 5G

The evolution of LTE Carrier Aggregation (CA) to support 5G involves increasing the number of aggregated component carriers (from 2-3 in LTE to potentially 16 in 5G), combining different frequency bands (like FDD and TDD), and moving to 5G Standalone (5G SA) networks.

This progression allows for higher peak data rates, greater flexibility for operators, and improved user experiences by maximizing bandwidth and network capacity, especially as more 5G frequency bands become available.

1. From LTE-Advanced to 5G:

• Foundation in LTE-Advanced: Carrier Aggregation was introduced in LTE-Advanced (Release 10) to boost data rates by combining multiple LTE component carriers. Initial commercial 5G development initially focused on Non-Standalone (NSA) 5G, which used a 4G LTE anchor and could aggregate with a 5G carrier for a speed boost.
• Transition to 5G SA: The shift to 5G Standalone (5G SA) networks is the next major step, where 5G CA can operate independently from the 4G network. This allows for the full benefits of 5G, including lower latency and higher speeds.

2. Key advancements in 5G CA:

• Increased number of carriers: 3GPP Release 15 for 5G NR supports aggregating up to 16 component carriers (CCs) for the downlink and 16 for the uplink, significantly more than the 5 CCs allowed in LTE-A.
• More carrier combinations: With more 5G frequency bands available, there are vastly more potential combinations for CA than in LTE. This allows for greater flexibility, such as combining FDD and TDD carriers from different frequency bands.
• Complex aggregations: Operators are deploying more complex CA configurations, such as three- and four-component carrier aggregation, to meet increasing data demands. For example, aggregating two TDD carriers or a combination of FDD and TDD carriers is a common commercial deployment.
• Support for different numerologies: 5G CA can aggregate carriers that use different numerologies (waveform characteristics), which is a significant technical advancement that was first commercially released by Ericsson in 2020.

3. Benefits of 5G CA:

• Higher speeds: Combining carriers increases the total available bandwidth, resulting in higher peak data rates.
• Improved network efficiency: CA allows operators to more efficiently use fragmented spectrum resources.
• Enhanced coverage: Aggregating low-band carriers with mid-band carriers can improve the coverage of the higher frequency bands, which is especially important for extending mid-band coverage.
• Better user experience: The combination of higher speeds and better network efficiency directly translates to an improved experience for end-users, supporting high-bandwidth applications like video streaming and online gaming.
