RAN Technology

- Overview

A Radio Access Network (RAN) connects a user's device to the core of a cellular network using radio waves. It has been a key component of cellular systems since 1979 and is essential for wireless communication.

With the growth of data traffic and 5G requirements, RANs are evolving to become more automated, adaptable, and efficient, often through the use of virtualization (vRANs) and cloud-native solutions like those from Ericsson.

1. What a RAN does:

• Connects devices: A RAN forms the radio part of a cellular network, linking devices like smartphones to the core network.
• Uses radio waves: It uses radio frequency to transmit and receive information between devices and the network's transceivers.
• Provides internet access: The transceivers in the RAN send data to the core network, which then provides access to the internet and other networks.

2. Challenges and modern solutions:

• Reaching performance limits: Traditional RANs struggle to handle the increasing demands of data traffic and the diverse needs of 5G.
• Need for virtualization: 5G requires more automation and flexibility, which led to the development of virtualized RANs (vRANs).
• Cloud-native approach: Solutions like Ericsson Cloud RAN handle RAN compute functions as cloud-native software, offering a more scalable and flexible alternative to hardware-based systems.

3. Benefits of vRAN and C-RAN:

• Reduced hardware costs
• Increased spectrum efficiency and faster speeds
• Greater scalability and flexibility
• Lower power consumption and heating

4. How operators expand capacity:

Mobile network operators can add capacity to their wireless networks in three main ways:

• Buy more spectrum: Acquire new radio frequency bands to increase capacity.
• Improve spectrum efficiency: Optimize how existing spectrum is used to transmit more data.
• Increase network density: Add more cell sites to improve coverage and capacity, particularly in areas with high demand.

- Modern RAN Architectures

C-RAN, vRAN, and Open RAN are different modern radio access network (RAN) architectures, with vRAN virtualizing baseband functions, C-RAN virtualizing and centralizing those functions on a cloud platform for efficiency, and Open RAN using open, interoperable interfaces to allow hardware and software from different vendors to work together.

These approaches are not mutually exclusive, and C-RAN is a form of vRAN, while Open RAN can be deployed with both vRAN and C-RAN principles.

1. Virtualized RAN (vRAN): A transformation from traditional RAN, where baseband processing is software-based rather than tightly integrated with hardware.

• How vRAN works: It virtualizes baseband unit (BBU) functions onto general-purpose hardware using technologies like Network Functions Virtualization (NFV). This creates more flexible, programmable, and efficient networks.
• Key characteristic: It disaggregates software from hardware, enabling virtualization and flexibility.

2. Cloud-RAN (C-RAN): A specific type of vRAN that centralizes virtualized RAN functions on a cloud infrastructure.

• How C-RAN works: It centralizes the processing from multiple cell sites in a single, remote location, allowing for dynamic and flexible resource allocation based on real-time demand.
• Key characteristic: It relies on both virtualization and centralization to achieve high efficiency.

3. Open RAN (O-RAN): An approach that standardizes the interfaces between different RAN components, like the radio unit (RU) and the central unit (CU) or distributed unit (DU).

• How O-RAN works: It replaces proprietary, single-vendor equipment with components that use open interfaces, allowing a multivendor ecosystem where operators can mix and match hardware and software from different suppliers.
• Key characteristic: Its primary focus is on open, interoperable interfaces, which drives innovation, competition, and cost reduction.

- 5G RAN

5G RAN is the radio access network for 5G cellular technology, which connects user devices to the internet via radio waves and supports faster speeds, greater capacity, and lower latency than previous generations.

It uses the 5G New Radio (NR) standard and can operate across a wide range of radio frequency bands, including low-frequency sub-6 GHz bands and high-frequency mmWave bands.

Challenges include mmWave limitations, public opinion, and remote recovery of equipment, which are being addressed with solutions like small cell technology and virtualization.

1. Key characteristics of 5G RAN:

• 5G New Radio (NR) standard: The specific radio interface and technology for 5G that supports a variety of frequency bands.
• Broadband support: Can use both sub-6 GHz and mmWave bands.
• Speed and capacity: Designed to deliver higher speeds and greater capacity compared to 4G.
• Latency: Aims for lower latency to support real-time applications.

2. Challenges in 5G RAN implementation:

3. Addressing challenges:

• Small cells: Deploying compact base stations on existing structures like buildings or street furniture can help overcome mmWave range limitations and address public opinion concerns.
• Virtualization (vRAN): Running baseband functions on standard servers as software, instead of on proprietary hardware, offers more flexibility, lower costs, and easier upgrades.
• Cloud-native functions: Applying cloud-native principles allows for more flexible and scalable deployment of RAN components.

- 6G and Beyond RAN

The first commercial deployment of 6G networks is expected around 2030, following standardization milestones later in the 2020s.

The 6G Radio Access Network (RAN) will be fundamentally an AI-native, open, and sensing-integrated platform designed to deliver unprecedented data rates (up to 1 Tbps), sub-millisecond latency, and global coverage. Key technologies for 6G RAN include:

1. Key Technologies for 6G RAN:

• AI and Machine Learning (AI/ML): AI will be embedded into the foundation of the network architecture, rather than being an add-on like in 5G. AI/ML will enable autonomous operations, intelligent resource management, traffic pattern forecasting, and dynamic spectrum allocation, making the network self-optimizing and self-sustaining.
• Terahertz (THz) and higher frequency communication: 6G will utilize spectrum in the mid-band (7-20 GHz), millimeter-wave (mmWave), and new sub-Terahertz/Terahertz (100 GHz to 10 THz) bands to achieve massive bandwidth and high data rates. This will require the deployment of ultra-dense small cells and advanced, high-gain antennas to manage signal propagation challenges.
• Integrated Sensing and Communication (ISAC): A major new capability of 6G, ISAC allows the network to use radio resources for both communication and environmental sensing simultaneously. This enables applications such as object detection, localization, environmental mapping, and real-time 4D mapping for autonomous mobility and smart city services.
• Open RAN (O-RAN) Architecture: Building on 5G trends, 6G RAN will prioritize open interfaces and disaggregated network functions, allowing operators to mix and match hardware and software from different vendors. This fosters a more competitive, innovative, and flexible ecosystem.
• Non-Terrestrial Networks (NTNs) Integration: Seamless connectivity will be achieved through the integration of terrestrial networks with satellite constellations, high-altitude platforms (HAPs), and drones. This ensures ubiquitous global coverage, even in remote areas.
• Cell-Free Networking & Ultra-Massive MIMO: Instead of traditional, fixed cell boundaries, 6G is moving towards a cell-free architecture where many distributed access points (APs) jointly serve user equipment. This, combined with ultra-massive Multiple-Input Multiple-Output (UM-MIMO), improves coverage, capacity, and user experience by dynamically creating highly-focused beams.
• Reconfigurable Intelligent Surfaces (RIS): RIS are a greener physical layer technology that can intelligently reflect and manipulate radio signals to bypass obstructions, extend coverage, and improve signal strength without requiring complex signal processing or significant power consumption.

2. Core Principles:

The development of 6G RAN is guided by several core principles:

• Sustainability: Energy efficiency is a key design goal, aiming for a 100-fold reduction in energy consumption compared to 5G through features like dynamic sleep modes and energy-efficient AI models.
• Security and Trustworthiness: The integration of AI and new technologies introduces new security and privacy challenges. 6G will incorporate advanced security mechanisms, such as quantum communication and blockchain, from the initial design phase.
• Extreme Performance: The network will be designed to support novel, data-intensive applications like holographic telepresence, wide-area mixed reality, and massive digital twinning, which require extreme data rates and ultra-low latency.
