Mobile IP

Zurich_Switzerland_DSC_0010
(Zurich, Switzerland - Alvin Wei-Cheng Wong)



- Overview

Mobile IP, an extension of the standard Internet Protocol (IP), allows mobile devices to maintain their IP address and ongoing communication sessions while transitioning between different networks. It ensures seamless connectivity and uninterrupted communication as users move between Wi-Fi, cellular, or other networks.

Key aspects of Mobile IP:

  • Maintaining IP Address: Mobile IP allows a device to keep its original, home IP address, even when connected to a different network (a foreign network).
  • Uninterrupted Communication: By maintaining the same IP address, Mobile IP avoids the need to re-establish connections and sessions when the device moves, preventing dropped calls or interrupted data transfers.
  • Mobility Support: It's particularly useful for devices that frequently switch between networks, like smartphones and laptops, enabling them to stay connected and maintain their online activities.
  • Standard Protocol: Mobile IP is an open standard (defined by the Internet Engineering Task Force or IETF).
  • Two Versions: Mobile IP exists for both IPv4 (Mobile IP) and IPv6 (Mobile IPv6).
  • How it works: Mobile IP involves components like a "Home Agent" (located on the device's home network) and a "Foreign Agent" (on the foreign network) to handle the routing of data to the mobile device.
  • Applications: Mobile IP is used in various scenarios, from mobile devices connecting to Wi-Fi while traveling to larger scale applications like in cellular networks.



Please refer to the following for more information:



- The Mobile IP Protocol (Mobile IP)

Mobile IP, defined by the IETF, enables mobile devices to roam between networks while preserving their IP address, using Mobile IPv4 and Mobile IPv6. It facilitates transparent routing of data, identifying mobile nodes by a home address regardless of location.

When away from home, a mobile node uses a care-of address to indicate its current location. This protocol ensures seamless connectivity during network changes by defining how mobile nodes register with their Home Agent (HA) and how the HA routes traffic via a tunnel.

The mobile IP protocol allows transparent routing of IP datagrams on the Internet. Each mobile node (cell phone, handheld, laptop PC, router), is identified by its HA, irrespective of its current location in the Internet. When away from home, a mobile node is associated with a care-of address, which provides information about its current location.

The mobile IP protocol specifies how a mobile node registers with its Home Agent (HA) and how the HA routes datagrams to the mobile node through a tunnel. Using mobile IP, nodes may change their point-of-attachment to the Internet without changing their IP address, allowing the application and transport-layer protocols to seamlessly maintain connection while moving.

Key aspects of Mobile IP:

  • IP Address Preservation: Mobile nodes retain their home address, even when moving between networks.
  • Care-of Address: A temporary address indicating the mobile node's current location, acquired when outside its home network.
  • Home Agent (HA): A router on the mobile node's home network responsible for intercepting and tunneling traffic to the mobile node's current location.
  • Tunneling: A mechanism where the HA encapsulates data packets and sends them to the mobile node's care-of address, allowing for transparent routing.
  • Agent Discovery: Mobile nodes detect their location by listening for advertisements from foreign agents.
  • Registration: Mobile nodes register their care-of address with their HA.



- The Characteristics of Mobile IP

Mobile IP provides several key characteristics that enable seamless communication for mobile devices while they move between different networks.

These features collectively allow Mobile IP to provide reliable and secure connectivity for mobile devices in a dynamic network environment, enabling them to roam across various networks while maintaining ongoing communication and applications.

The general characteristics of mobile IP can be summarized as follows:

  • Transparency: Mobile IP ensures that higher-level protocols like TCP/IP and applications are unaware of network changes as the mobile device moves. This allows applications to continue functioning without interruption, as if the device remained on the same network.
  • Interoperability: Mobile IP is designed to be compatible with existing IP networks and infrastructure, minimizing the need for significant modifications or new equipment to support mobile users. This means it can integrate into both wired and wireless networks.
  • Scalability: Mobile IP can effectively support a large number of mobile devices and networks, making it a suitable solution for the growing number of internet-connected mobile users and the expanding reach of wireless networks.
  • Security: Mobile IP includes security mechanisms like authentication to prevent unauthorized access, data interception, and attacks using fake IP addresses, ensuring the integrity and confidentiality of mobile communications.
  • Macro mobility: Mobile IP is well-suited for enabling users to maintain long-term connections while moving between different network domains, facilitating continuous connectivity even when far from their home network. This allows mobile nodes to seamlessly switch between different networks while keeping the same home IP address.


- Types of Entities in Mobile IP

Node mobility is realized without propagating host-specific routes throughout the Internet. Using mobile IP, a mobile device will have two addresses, i.e., a primary or permanent home address and a secondary or temporary care-of address, which is associated with the network that the mobile node is visiting.

In essence, these entities work together to ensure that a mobile device can maintain communication even when it moves to different networks by allowing the device to retain its original home IP address while using a temporary care-of address to receive data at its new location.

Mobile IP involves three main entities:

  • Mobile Node (MN): This refers to the mobile device (e.g., laptop, smartphone) that moves between networks while maintaining the same home IP address.
  • Home Agent (HA): A router or server on the Mobile Node's home network that plays a crucial role when the Mobile Node (MN) is away from its home network. The HA intercepts datagrams destined for the MN and tunnels them to the MN's care-of address (its current location). The HA also maintains a record of the MN's current location.
  • Foreign Agent (FA): A router or server on the foreign network that the Mobile Node (MN) is visiting. The FA provides routing services to the MN while it's registered on the foreign network. The FA might also provide the MN with a care-of address while the MN is registered. In addition, the FA can also advertise its services on the network using agent advertisement messages.



- Node Mobility

In Mobile IP, when a mobile node (MN) wishes to communicate with another device (referred to as a Correspondent Node or CN), it leverages its permanent home address for outgoing packets. However, this address, while serving as a consistent identifier, might not reflect the mobile node's current physical location if it's roaming outside its home network.

In essence, Mobile IP ensures that a mobile device can maintain continuous communication even while moving between different networks by transparently redirecting packets destined for its home address to its current location using tunneling and registration mechanisms. Triangular routing is the default for outgoing packets from the MN, but reverse tunneling offers a solution for networks with ingress filtering.

Here's how Mobile IP ensures seamless communication even when a mobile node is away from home:

1. Addressing and Routing:

  • The home address is logically linked to the home network and its Home Agent (HA). Thus, regular IP routing directs packets destined for the MN to the HA, even if the MN isn't physically present in its home network.



2. Packet Redirection:

  • The HA, recognizing the MN's absence, doesn't simply forward the packets to the home network. Instead, it redirects them towards the MN's current location, which is identified by a Care-of Address (CoA).


3. Tunneling:

  • To achieve this redirection, the HA consults its mobility binding table to find the MN's CoA. It then tunnels the packets to this CoA by adding a new IP header to the original packet, encapsulating the original IP header. This technique is known as encapsulation or tunneling.


4. Packet Delivery:

  • The packets, carried within this tunnel, arrive at the tunnel endpoint (which could be a Foreign Agent (FA) or the MN itself if using a co-located CoA). The tunnel endpoint then removes the extra IP header and delivers the original packet to the MN.


5. Triangular Routing:

  • When the MN sends packets back to the CN, it directly transmits them through the FA (without HA involvement). It uses its permanent home address as the source IP address in these packets. This direct path for outgoing packets while incoming packets go through the HA is known as triangular routing.


7. Reverse Tunneling (Addressing Ingress Filtering):

  • Some networks employ ingress filtering, where gateway routers verify if the source IP address of a packet belongs to the router's subnet. In such cases, packets originating from the MN, using its home address in a foreign network, might be discarded. To overcome this, reverse tunneling is employed. Here, the FA tunnels the MN's outgoing packets back to the HA, and the HA then forwards them to the CN, ensuring a topologically correct source address for these packets.


8. Mobile IP Protocol Details:

Mobile IP is defined by a protocol that includes several key procedures.

These include:

  • Authenticated registration: A secure process for the MN to register its CoA with its HA.
  • Router discovery: Allows the MN to locate potential HAs and FAs.
  • Packet routing rules: Specifies how packets are routed to and from the MN, including different tunneling options.


- 5G and IP Addresses

5G, as a wireless technology, doesn't have its own IP address. While 5G enables devices to connect to the internet and access IP addresses, it utilizes MAC addresses for local network identification.

When a 5G device connects to a LAN, it receives an IP address from a DHCP server, and when connecting to a carrier network, the carrier assigns the IP address.

Here's a more detailed explanation:

  • 5G and IP Addresses: 5G facilitates internet connectivity, but it doesn't have a direct IP address like a computer or smartphone. Instead, it uses a MAC address for local network identification on a 5G LAN.
  • DHCP and IP Assignment: When a 5G device connects to a local network (5G LAN), it broadcasts a DHCP request. The DHCP server then assigns an IP address and other network configuration details.
  • Carrier Network Assignment: When a 5G cellular interface connects to a carrier network, the carrier automatically assigns an IP address to that interface.
  • IPv6 and 5G: While IPv6 addressing has been proposed to support 5G, IPv4 will continue to be used alongside IPv6 until networks fully transition to IPv6, according to a report from icann.
  • 5G's Role: 5G acts as a conduit for devices to connect to the internet, enabling various applications and services that rely on IP addresses for communication.





[More to come ...]
