ANNs and Multilayer Perceptrons

MIT_Stata_Center_01
(Stata Center, MIT - Yu-Chih Ko)


- Overview

A Multilayer Perceptron (MLP) is a type of artificial neural network (ANN) that consists of multiple layers of interconnected nodes, or neurons, used to learn complex patterns from data. It's a powerful model for tasks like classification, regression, and pattern recognition.

  • Layers: MLPs typically have three layers: an input layer, one or more hidden layers, and an output layer.
  • Neurons: Each layer contains multiple neurons (or nodes) that process information.
  • Connections: Neurons in adjacent layers are fully connected, meaning each neuron in one layer is connected to every neuron in the next layer.
  • Activation Functions: Activation functions in neural networks are mathematical equations that determine the output of a neuron based on its input, essentially deciding whether a neuron should be "activated" or not. They introduce non-linearity into the model, enabling it to learn complex patterns and relationships in data.  Neurons use activation functions (like sigmoid or tanh) to introduce non-linearity, allowing the network to learn complex relationships in data.
  • Backpropagation: MLPs are trained using backpropagation, an algorithm that iteratively adjusts the network's weights and biases based on the difference between predicted and actual outputs.
  • Optimization: Optimization algorithms (like stochastic gradient descent or Adam optimizer) are used to refine the weights and biases during training.



- ANNs vs Perceptrons

Artificial Neural Networks (ANNs) and MultiLayer Perceptrons (MLPs) are both types of neural networks used in machine learning (ML).

Here are some differences between ANNs and perceptrons:

  • ANNs: A computational model inspired by the biological neural networks in the human brain. ANN models can be single or multi-layered. Any network with more than two layers is a deep neural network.
  • Perceptrons: A neural network unit that performs computations to detect features or business intelligence in the input data. Perceptrons are a simple type of artificial neuron used for binary classification.



Perceptrons use different weights for each signal. They also use the threshold function, while adaline uses a linear activation function.

MLPs are a type of ANN with a specific architecture. MLPs are fully connected multi-layer neural networks with three layers, including one hidden layer. If it has more than one hidden layer, it is called a deep ANN.

MLPs extend the concept of artificial neurons into hidden layers, enabling the modeling of complex relationships in data.



- Activation Functions in Neural Networks

An activation function in neural networks is a mathematical function applied to the output of a neuron. It introduces nonlinearity to the model, enabling the network to learn and represent complex patterns in the data. Without this nonlinearity, a neural network would behave like a linear regression model, no matter how many layers it has.

An activation function decides whether a neuron should be activated or not by calculating a weighted sum of the inputs and adding a bias term. This helps the model make complex decisions and predictions by introducing nonlinearity in the output of each neuron.

1. What activation functions do:

  • Introduce non-linearity: Without activation functions, a neural network would essentially be a linear regression model, regardless of how many layers it has. Activation functions allow the network to learn non-linear relationships in the data.
  • Determine neuron activation: They take the weighted sum of a neuron's inputs (plus a bias) and produce an output value. This output value determines whether the neuron is activated and how strongly it passes information to the next layer.
  • Map input to output: They transform the input signal of a node into an output signal.


2. Why activation function are important:

  • Learning complex patterns: Activation functions are crucial for enabling neural networks to learn intricate patterns and relationships in data.
  • Enabling deep learning: They allow for the construction of deep neural networks with multiple layers, which are capable of learning more complex representations of data.
  • Flexibility in model design: Different activation functions have different properties and are suitable for different types of tasks and network architectures.


3. Examples of common activation functions:

  • Sigmoid: A sigmoid function outputs a value between 0 and 1, often used for binary classification problems.
  • Tanh: The hyperbolic tangent function outputs values between -1 and 1, similar to sigmoid but with a wider range.
  • ReLU (Rectified Linear Unit): ReLU outputs the input if it's positive, and 0 otherwise. It's computationally efficient and commonly used in deep neural networks.
  • Leaky ReLU: An extension of ReLU that outputs a small negative value for negative inputs, helping to address the "dying ReLU" problem.
  • Softmax: Softmax outputs a probability distribution over multiple classes, making it suitable for multi-class classification.



- Multi-Layer Perceptron and Backpropagation

A Multilayer Perceptron (MLP) is a type of neural network that uses multiple layers of connected nodes (neurons) to learn complex patterns in data. Backpropagation is the algorithm used to train these MLPs, adjusting the connections (weights) between neurons to minimize errors and improve accuracy.

1. Multilayer Perceptron (MLP):

  • Structure: MLPs are composed of multiple layers: an input layer, one or more hidden layers, and an output layer.
  • Connections: Each neuron in a layer is connected to every neuron in the next layer.
  • Learning: MLPs learn by adjusting the weights (strengths) of these connections based on training examples.
  • Purpose: MLPs are powerful tools for modeling complex relationships between inputs and outputs, making them suitable for various tasks like classification and regression.



2. Backpropagation:

  • Training Algorithm: Backpropagation is the primary algorithm used to train MLPs.
  • Error Minimization: It works by comparing the network's output with the actual output and then adjusting the weights to minimize the difference (error).
  • Forward Pass: Data flows forward through the network, from the input layer to the output layer, resulting in an output.
  • Backward Pass: The error is then calculated and propagated backward through the network, from the output layer to the input layer.
  • Weight Adjustment: Based on the error, backpropagation adjusts the weights of the connections to improve the network's accuracy in subsequent passes.

In essence: MLP is the structure of the neural network, while backpropagation is the method used to train and improve its performance. MLPs use backpropagation to learn from data and make accurate predictions on new, unseen data.



- Optimization Algorithms in Neural Networks

Optimization algorithms like Stochastic Gradient Descent (SGD) and the Adam optimizer are crucial for refining the weights and biases of a neural network during the training process.

These algorithms work by iteratively adjusting the model's parameters (weights and biases) to minimize a cost function, which measures the difference between the model's predictions and the true labels.

  • Weights and Biases: In a neural network, weights and biases are parameters that determine how different input features are combined and how much each neuron contributes to the overall output.
  • Cost Function: The cost function quantifies the error or loss of the model's predictions. The goal of optimization algorithms is to find the set of weights and biases that minimizes this cost function.
  • Stochastic Gradient Descent (SGD): SGD is an iterative optimization algorithm that updates the model's parameters based on the gradient of the cost function with respect to those parameters. In essence, SGD adjusts the weights and biases in the direction that reduces the cost function the most.
  • Adam Optimizer: Adam is another popular optimization algorithm that extends SGD by incorporating momentum and adaptive learning rates. It can often lead to faster and more stable convergence during training, especially for complex models and noisy data. Adam combines the benefits of momentum and RMSprop to provide more efficient and adaptive updates to the network weights during deep learning training.
  • Iterative Refinement: During training, these optimization algorithms repeatedly adjust the weights and biases based on the gradients of the cost function, gradually refining the model's parameters to achieve the desired level of accuracy.





[More to come ...]
